Horizontal Laminar Air Flow
A Laminar Air Flow Workstation creates a sterile environment for sensitive processes using HEPA Filteration system. It provides Unidirectional airflow at 0.4-0.6 m/s, minimizing turbulence and reducing contamination. While it protects product from room contamination, it does not offer personal protection for User.
Horizontal LAF: Horizontal Laminar Air Flow Workstation is designed to provide a clean, particle-free working environment for sensitive laboratory applications. The system draws ambient air through a pre-filter and HEPA filter mounted at the rear, delivering unidirectional horizontal airflow (back to front) across the work surface. This airflow pattern effectively protects the product from contamination, ensuring high process integrity; however, it does not provide personnel protection.
Horizontal LAF: Horizontal Laminar Air Flow Workstation is designed to provide a clean, particle-free working environment for sensitive laboratory applications. The system draws ambient air through a pre-filter and HEPA filter mounted at the rear, delivering unidirectional horizontal airflow (back to front) across the work surface. This airflow pattern effectively protects the product from contamination, ensuring high process integrity; however, it does not provide personnel protection.
Technical Parameters
| Contruction: | Stainless Steel/ Powder Coated |
|---|---|
| Switches: | Microprocessor based switches for Blower, LED light & UV light with LED back light display (UV light With Timer.) |
| Airflow: | Frontward Horizontally (Back to Front) |
| Air Filteration: | Pre Filter 5 Micron, HEPA Filter 0.3 micron |
| Noise Level: | 60 decibel ± 5% |
| Velocity: | 0.35-0.50m/sec |
| Work Table: | Made up of stainless steel 304gr Cock for gas on work table. |
| Front door: | Manual Foldable/ Sliding Door/ Motorized Sliding Door. |
| UV Lamp: | 15/30W, make Philips Holland LED |
| Illumination: | LED / Fluorescent Light for easy operation. |
| Pressure: | Manometer 0-50mm range with filter failure alarm. |
| Power Supply: | 230V±10V/50 Hz single phase AC |
| Heavy Duty Blower: | Dynamically balanced with 0.25 HP Electric Motor Mounted on anti vibration pad 1440 RPM motor. |
| Stand: | Bench Top, Free Standing or Free Standing with Wheels. |
| Front Door Material: | Glass/ Acrylic/ Poly Carbonate |
OPTIONAL
| A | Digital Pressure Gauge Alarm |
| B | HMI Based Touch Screen Panel |
| C | Filter Choke Alarm |
| Model | Dimension (ft) | Dimension (MM) |
|---|---|---|
| ΤΑΙ-954-1 | 3x2x2 | 600x600x600 |
| ΤΑΙ-954-2 | 3x2x2 | 900x600x600 |
| ΤΑΙ-954-3 | 4x2x2 | 1200x600x600 |
| ΤΑΙ-954-4 | 6x2x2 | 1500x600x600 |
